1. Introduction for beer brew system

We offer a Microbrewery with the productivity 2000L per brew.

The service includes: complete set of microbrewery equipment, installation turn key, recipes and technology of branded beers, staff training and more.



1.Specification of beer brew pub system

Output per brew: 2000L

Brew per week: 2-6

Output per week: 4000~12000L

Electric supply: 3Phase/380(220,415...)V/60(50)HZ;

Heating source: Steam/Direct fire

Area request: >150㎡

Brewmaster: 1

Install power: 20KW

Pump with ABB motor

Steam request:0.2Ton/Hr

Water consumption: 3m³ /Day


2. Configuration of beer brew system

Malt Milling Unit (1000kg/h)

Particle adjustable rolling crusher

Flex auger, grist case for option.


Brewhouse Unit (2000L)

Mash/Lauter tun, Boiling Kettle/Whirlpool tun

Hot water tank and cold water tank for optional in special combinations

Infusion or decoction brewing methods are designed exactly

Stainless steel or copper cladding are popular

Two stages or single stage heat exchanger for wort cooling

Completely stainless steel integrated work platform

Sanitary and efficiency wort pump

All pipings and fittings


Fermentation Unit (2000L or 4000L for option)

Standard stainless steel conical cylindrical fermentation tanks

Single size as brewhouse is common used in micro brewery; Or you can make your fermentation tanks be 4000L so as double the output.

Tanks quantity is exactly calculated by fermentation cycle for various beers

All manhole, valves, pressure gauges, fittings etc are included


Cooling Unit

Insulated glycol water tank with or without copper coil for glycol liquid holding and mixing

Efficiency chillers or refrigerators with fryonto supply cooling energy

Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger

All pipes, fitting, insulation materials are included


Controlling Unit

Electrical controlling cabinet with temperature, on-off controlling for brewhouse

Electrical controlling cabinet with temperature, on-off controlling for cooling parts

Temperature controller, thermocouple, solenoid valves etc are included

PLC with touch screen panel for special request


CIP System

Portable CIP system for cleaning the tanks
